LockeyUSA 2210 DC User Manual
Page 2
Step 7 cont: Install the Lockey 2210
1. Insert the Spindle (#7/8) into the Outside
Body (#1) ensuring it’s in the
proper angled position.
*(SEE FIGURES BELOW)
2. Using a screwdriver, secure
the lock to the door with
the Screws (#9 or #10).
Screw length dependent on
door thickness.
3. Test the operation of the
Deadbolt by turning the inside knob.
4. Locate position where Deadbolt strikes door frame
And install Mortised Strike (#4).
*IMPORTANT: SPINDLE POSITION/ANGLE
RIGHT-HAND DOORS: From inside,
place spindle through Deadbolt, into the
Outside Body (#1) in the 2:00/8:00
position as shown to right.
LEFT-HAND DOORS: From inside,
place spindle through Deadbolt, into the
Outside Body (#1) in the 10:00/4:00
position as shown to right.
