1.1 Hardware Features
Standards
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3z Gigabit fiber
IEEE 802.3ab 1000Base-T
IEEE 802.3x Flow control and Back pressure
IEEE 802.3ad Port trunk with LACP
IEEE 802.1d Spanning tree protocol
IEEE 802.1w Rapid spanning tree
IEEE 802.1p Class of service
IEEE 802.1q VLAN Tagging
IEEE 802.1x User authentication
IEEE 802.1ab LLDP
LED Indicators
System Power
10/100/1000TX module: Link/Activity, 1000/100/10Mbps
speed
8 Port Gigabit Fiber module: Link/Activity
8 Port MINI GBIC: Link/Activity
4 Port Gigabit copper + 4 Port MINI GBIC module: RJ-45
(Link/Activity, 1000/100/10Mbps speed), MINI GBIC
(Link/Activity)
Connector
RS-232 console: Female DB-9
Gigabit copper module: 8 x RJ-45
MINI GBIC module: 8 x MINI GBIC socket
Gigabit Fiber module: 8 x SC for Gigabit SX or LX
4 Gigabit Copper & 4 MINI GBIC module: 4 x RJ-45 + 4 x
3.3v MINI GBIC Socket
Switch architecture Store and forward switch architecture with Back-plane up to
