4. Specifications
11
4. Specifications
General
Host Interface USB 3.0 (and USB 2.0 compliant)
Operating System Support  Windows

XP, Windows

7, Windows

8
 Mac OS10.6 and later.
Ports and Connectors
Upstream 1 x Upstream USB 3.0 Port (Type A male Connector)
Ethernet 1 x Ethernet Port (RJ-45 connector)
LED
Link LED (Amber)  On: When connection to a 1000Mbps network
 Off: When connection to a 10/100Mbps network
Status LED (Green)
 On/Blinking: LAN activity.
 Off: No network traffic .
Power
Power Mode USB Bus -powered
Power Consumption  Operating Mode: 420 mA
 Suspend Mode : 38 mA
Physical Specifications
Housing Material ABS (Plastic)
Dimensions  Main body without cable: 84 mm(W) x 23 mm(D) x 15 mm(H)
 Main body with cable: 97 mm (W) x 23 mm(D) x 15 mm(H)
Weight Approximately 46 g (including cable)
Environmental Specifications
Operating Temperature 10-40°C
Storage Temperature -10~80°C
