User's Manual - 9
Set up the Video Server through Power over Ethernet (PoE)
When using a PoE-enabled switch
The video server is PoE-compliant, allowing transmission of power and data via a single
Ethernet cable. Follow the below illustration to connect the video server to a PoE-enabled switch
via Ethernet cable.
When using a non-PoE switch
If your switch/router does not support PoE, use a PoE power injector (optional) to connect
between the video server and a non-PoE switch.
Non-PoE Switch
PoE Power Injector
(optional)
