We are delighted that you have purchased one
of our products.
These are usage instructions to help you
familiarize yourself with your new purchase.
All the documents accompanying the product
must be read attentively before using the
product, preserved carefully and if the product
is transferred to a third party, the documents
must be handed over as well. This ensures that
maximum benefit is drawn from the product
and questions from users are anticipated before
they arise.
Above all, comply with the warnings and safety
instructions and dispose of the packaging
material properly.
Additional information for H14.2 with “TEST IT”
function
Your LED LENSER H14.2 headlamp is packaged
with a “TEST IT” function (item no. 7399). This
allows users to test the brightness while the
product is still in the package. For testing,
simply push the yellow TEST IT button on the
front of the package. When testing, please do
not look directly into the light.
The TEST IT button is connected to the battery
housing of the H14.2 via two wires and should
be removed prior to use.
To remove the “TEST IT” button and wires,
open the battery housing and remove the 4XAA
battery (see also “Changing of the alkaline
battery” further below). Separate the two “TEST
IT” button wires from the battery housing by
pulling on each wire until it releases from the
battery housing. Insert the 4XAA batteries and
noting the correct polarity. Close the battery
housing. Please dispose and recycle the
packaging and “TEST IT” button with the wires
according to the local regulations.
Product
7299, LED LENSER® H14.2
7399, LED LENSER® H14.2 (blister)
Version of the operating manual: 1.3
1. Battery set:
- 4 x AA/LR06(1.5 V DC)
2. Turning it ON and OFF
There are two switches on the H14.2.The
front switch is located in the upper part of the
headlamp housing. This button is used to turn
the H14.2 ON/OFF. It is also used to activate the
various Light Programs, Lighting Functions (see
Section 5.1) and to active the “transport lock”
functions (see Section 7).
The “Multi-function Wheel” switch is located
on the backside in the upper part of the battery
box. This allows you to adjust infinitely the
brightness (down to 5 lm), flash rate and to
change the light modes (see Section 5.1).
3. Focus
In the front, narrower region of the headlamp
housing is the reflector lens through which the
light of the LED is focusable. Adjust the focus
by easily pulling and pushing the front cap. This
is our patented “Speed Focus” system, which
allows the adjustment of the light beam’s focus.
You also can adjust the hinge of the headlamp,
depending on whether you want to illuminate
an area in the distance or in front of you. For
this, you simply tilt the part of the head lamp
containing the reflector lens and the LED.
4. Smart Light Technology (SLT)
Smart Light Technology (SLT) is a program that
consists of computer optimized microcontrollers
which allows our products to have various
lighting functions. The H14.2 is equipped with
this technology and is therefore able to use
various Light Programs and Functions with an
interface that is simple and user friendly. With
the Multi-function “Wheel” switch on the back,
the light intensity (down to 5 lm) and flashing
rate (1–24Hz) is infinitely adjustable simply
by rotating the switch. By pressing the “Multi-
function Wheel” switch you can change the light
mode.
5. Light Programs and Light Functions
The H14.2 is equipped with one LED (Light
Emitting Diode). The white LED is very strong
and ideal for normal use. For example if the
Speed Focus or the adjustment of the angle of
light beam to the horizontal should be used.
The boost mode of H14.2 can be turned on when
the flashlight is off and then pushing the front
switch for approx. 5 seconds. Release the switch
when the boosted light is on otherwise the
product will enter “transport lock” (see Section
7).
5.1 Light Program
In H14.2, there are three different modes (Easy
Low, Easy Power, Signal). The default mode is
the Easy Low
When the product is off, press the “Multi-function
Wheel” switch on the back for 5 second. It will
achieve transition mode. Then the LED will blink
once (3Hz) to indicate that it is mode one; then
blink twice for mode two; and finally blink thrice
for mode three.
a) Light Mode one - Easy Low: when the product
is off, firmly press the front button until it blinks
once. The LED will glow at its lowest brightness
(light function: Low Power). A second touch
to the button on top of the lamp will turn ion
the lamp to its full brightness (light function:
Power), and third touch will turn the lamp off.
b) Light Mode two - Easy Power: when the
product is off, firmly press the front button until
it blinks twice. The LED will glow at its fullest
brightness (light function: Power). A second
touch to the button on top of the lamp will
turn on the lamp to its lowest brightness (light
function: Low Power), and third touch will turn
the lamp off.
c) Light Mode three - Signal: when the product
is off, firmly press the front button until it blinks
thrice. The LED will glows with full brightness
(light function: Power). A second touch to the
button on top of the lamp will start the strobe (12
Hz) (light function: Pulse), and a third touch will
turn the lamp off. The speed at which the strobe
will blink can be adjusted by turning the “Multi-
function Wheel” switch on the back.
Note: In the low power- and power- function,
you can adjust the brightness stepless by
turning the multi-function "Wheel" switch ( Dim-
02
