LA STEELCRAFT 12054PC - Manual (Page 2)

PHN 626-798-7401 FAX 626-798-1482
DRAWN BY: AFS DO NOT SCALE DRAWING
STEELCRAFT PRODUCTS
P.O. Box 90365 - Pasadena, CA 91109
MODEL
30" DIA. X 54" DEEP
CONC. FOOTING
3
FOR GOAL & BACKBOARD
w/ HOLE PATTERN
WELDED TO PIPE
(SUPPLIED BY OTHERS)
1
2
6" X 6" X 3/16" PLATE
1" OD PIPE WELDED TO SIDE
OF POST TO PREVENT ROTATION
WHILE IN-GROUND
4'-0" IN GRD.
TO TOP OF POST
MIN. OF 12'-6"
FROM FINISH GRADE
NOTE: NUMBER OF BRACES VARIES BY MODEL OF BACKBOARD
DATE: 8/25/09
NOTE: SPECIFICATIONS ARE SUBJECT TO CHANGE
w/ RECT. SHAPE EXT.
12054PC
BASKETBALL POST
ITEM QTY. DESCRIPTION
1 1
5-9/16"OD POWDER COATED PIPE w/ WELDED CAP
& 4'-0" EXT.
2 1 4'-0" EXT. FRAME
3 1 1" OD P/C TUBE BRACING
