Joyce Electric Cylinders with Ball Screw - Manual (Page 9)

9
3-3 Ball Screw Electric Cylinder Parts Numbers (continued)
Model
Number
ECBL65
ECBL125
ECBL245
ECBM65
ECBM125
ECBM245
ECBH65
ECBH125
ECBH245
ECBL810
ECBL2410
ECBM810
ECBM2410
EBH810
ECBH2410
ECBL820
ECBL2420
Static
Capacity 5 TON 5 TON 5TON 10 TON 10 TON 10 TON 20 TON
Lifting
Screw
Diameter
(inches)
1.5 1.5 1.5 1.5 1.5 2.25 2.25
Thread
Pitch/ Lead
(inches)
.474 1.00 1.875 .474 1 1.875 .5
Worm Gear
Ratio
6:1
12:1
24:2
6:1
12:1
24:2
6:1
12:1
24:2
8:1
24:1
8:1
24:1
8:1
24:1
8:1
24:1
Worm Shaft
Turns for 1"
Travel
12.66
25.33
50.66 6
12
24
3.2
6.4
12.8
16.88
50.66 8
24
4.27
12.8 16
48
Tare Torque
(inch/Lbs.)
15
13
12 15
13
12 15
13
12 30
25 30
25 30
25 60
40
Starting
Torque
(Inch/lbs.)
.032W*
.020W*
.015W* .067W*
.042W*
.031W* .125W*
.079W*
.057W* .023W*
.012W *
.049W*
.024W* .091W*
.045W* .026W*
.014W*
Operating
Torque †
(inch lbs.) @
Worm RPM
.025W*
.014W*
.009W*
@ 300 RPM
.052W*
.030W*
.018W8
@ 300 RPM
.098W*
.055W*
.034W*
@ 300 RPM
.019W*
.008W*
@ 200 RPM
.040W*
.017W*
@ 200 RPM
.074W*
.031W*
@ 200 RPM
.020W*
.096W*
@ 200 RPM
Translating
Tube Torque
* (inch lbs.)
.084W .177W* .332W* .084W* .172W* .332W .089W*
Base Weight
( lbs)
65 65 65 81 81 81 164
Add to Basic
Jack Weight
(lbs.) for
each
Additional 1"
of Travel
2.3 2.3 2.3 2.3 2.3 2.3 4.5
Max. Vertical
Rise
54” 40” 59” 38” 38” 41”
72”
Max.
Horizontal
Rise
40” 38” 44” 28” 28” 31” 54”
W*= Load in pounds
Tare Torque: The initial torque needed to overcome seal and normal assembly drag. This value must be added to starting torque
or operating torque values.
Starting Torque: Torque value required to start moving a given load (dissipates to operating torque value once the load begins
moving).
Operating Torque: Torque required to continuously raise a given load at the input RPM listed.
Translating Tube Torque: Torque required to resist the tube rotation.
