Joyce ACME SCREW Electric Cylinders (Standard, Motor mount, and ComDRIVE style) - Manual (Page 9)

9
3-3 ACME Screw Electric Cylinder Parts Numbers (continued)
Model
Number
ECAL810
ECAL2410
ECAM810
ECAM2410
ECAH810
ECAH2410
ECAL820
ECAL2420
ECAM820
ECAM2420
ECAH820
ECAH2420
Static
Capacity 10 TON 10 TON 10 TON 20 TON 20 TON 20 TON
Lifting
Screw
Diameter
(inches)
2 2 2 2 1/2 2 1/2 2 1/2
Thread
Pitch/ Lead
(inches)
.25 .50 .33 / .66 .25 .50 .375/.75
Worm Gear
Ratio
8:1
24:1
8:1
24:1
8:1
24:1
8:1
24:1
8:1
24:1
8:1
24:1
Worm Shaft
Turns for 1"
Travel
32
96 16
48 12
36 32
96 16
48 10.67
32
Tare Torque
(inch/Lbs.)
30
25 30
25 30
25 60
40 60
40 60
40
Starting
Torque
(Inch/lbs.)
.052W*
.026W* .061W*
.031W* .070W*
.035W* .066W*
.035W *
.075W*
.039W* .088W*
.046W*
Operating
Torque †
(inch lbs.) @
Worm RPM
.036W*
.016W*
@ 200 RPM
.044W*
.019W*
@ 200 RPM
.051W*
.022W*
@ 200 RPM
.044W*
.019W*
@ 200 RPM
.052W*
.022W*
@ 200 RPM
.062W*
.027W*
@ 200 RPM
Translating
Tube Torque
* (inch lbs.)
.162W .195W* .228W* .194W* .227W* .273W*
Base Weight
( lbs)
64 64 64 124 124 124
Add to Basic
Jack Weight
(lbs.) for
each
Additional 1"
of Travel
2.8 2.6 2.7 4.9 4.7 4.8
Max. Vertical
Rise
84” 60” 76” 100” 78” 88”
Max.
Horizontal
Rise
63” 45” 57” 75” 58” 66”
W*= Load in pounds
Tare Torque: The initial torque needed to overcome seal and normal assembly drag. This value must be added to starting torque
or operating torque values.
Starting Torque: Torque value required to start moving a given load (dissipates to operating torque value once the load begins
moving).
Operating Torque: Torque required to continuously raise a given load at the input RPM listed.
Translating Tube Torque: Torque required to resist the tube rotation.
