PROFESSIONAL POWER AMPLIFIER
Specifications Specifications
(U.K/Australia Version)
0dB=1V
V2-1000 V2-2000 V2-3000 V2-4000
240VAC 240VAC 240VAC 240VAC
Continuous Average Output Power Per Channel
Stereo Mode 8Ω (T.H.D 0.1%) 170W 280W 500W 650W
(1kHz, Both Channels Driven) 4Ω (T.H.D 0.1%) 300W 500W 900W 1150W
2Ω (T.H.D 0.5%) 500W 850W 1400W 1800W
Bridged Mono Mode 8Ω (T.H.D 0.1%) 650W 1000W 1800W 2400W
4Ω (T.H.D 0.5%) 1100W 1700W 3000W 3800W
Input Sensitivity (Rated Output Power @4Ω) 1V
Voltage Gain (Rated Output Power @4Ω) 31dB 33dB 36dB 37dB
Frequency Response 20Hz~20kHz ±0.3dB
(1W @8Ω) - 3dB point 5Hz~70kHz
Damping Factor (100Hz, Rated Output Power @8Ω) more than 380 more than 450 more than 400
T.H.D
less than 0.05%
(20Hz~20kHz, 10dB Below Rated Output Power @4Ω)
Channel Separation
less than 70dB
(1kHz, 3dB Below Rated Output Power @8Ω)
Residual Noise
less than 75dB less than 73dB
Signal to Noise Ratio
106dB
(Rated Output Power @8Ω, 20Hz~20kHz)
Output Circuitry
Class AB 2 Step Class H
Input Impedance 12 kΩ Balanced
HPF (30Hz/50Hz) 12dB/oct
Indicators Prot/Clip, Signal, Power
Protection Circuitry
Full Short Circuit, Thermal Protection
Power ON/OFF Muting, DC Output Protection
Cooling Variable Speed Fans, Front to Rear Air Flow
Connectors Input : XLR(Female), 1/4 ″TRS,
Output : 4 Pole Speaker Socket
Operating Temperature/Humidity Temperature : -10 °C ~ +40 °C / Humidity : 0% ~ 90%
Power Source
240VAC
50Hz
Power Consumption
4A 5A 6A 7A
(1/8 Rated output power @4 Ω )
Weight (SET) 10.7kg / 23.6lb 10.9kg / 24lb 12kg / 26.4lb 12.1kg / 26.7lb
Dimensions (SET) 482(W) x 88(H) x 407(D)mm / 19(W) x 3.5(H) x 16(D)in
* Specifications and design subject to change without notice.
