13 PAM-510/520
ATT. ZONE AMPLIFIER
Specifications Specifications ................................................................
*0dBV=1Vrms
AMPLIFIER SECTION (AMP IN@1kHz, 4ohm LOAD OUTPUT)
Rated Output Power (THD 1%)................................................PAM-510: 120W(RMS), PAM-520: 240W(RMS)
※SPEAKER ZONE 1~5 OUTPUT.................................................PAM-510: 25W MAX, PAM-520: 50W MAX
Input Sensitivity/Impedance ............................................................................................................1V/20k
Ω
Signal-to-Noise Ratio ...........................................................................................................Better than 85dB
Frequency Response (at 1kHz Half Power Output, ±3dB) .............................................................80Hz~18kHz
MIC INPUT SECTION (MIC 1~4 IN@1kHz, PREAMP OUT)
Input Sensitivity/Impedance ....................................................................................................–60dBV/600 Ω
Signal-to-Noise Ratio ...........................................................................................................Better than 55dB
Frequency Response (±3dB).....................................................................................................120Hz~10kHz
Tone Control(BASS: 100Hz, TREBLE: 10kHz) ........................................................................................±12dB
PHANTOM POWER ........................................................................................................................+24VDC
LINE INPUT SECTION (LINE 1~2 IN@1kHz, PREAMP OUT)
Input Sensitivity/Impedance.....................................................................................................–30dBV/10k Ω
Signal-to-Noise Ratio ...........................................................................................................Better than 65dB
Frequency Response (±3dB).......................................................................................................80Hz~15kHz
Tone Control (BASS: 100Hz, TREBLE: 10kHz) .......................................................................................±12dB
REMOTE AMP SECTION (REMOTE IN@1kHz, PREAMP OUT)
MIC Input Sensitivity/Impedance .............................................................................................–60dBV/600 Ω
Signal-to-Noise Ratio ...........................................................................................................Better than 55dB
Frequency Response (±3dB).....................................................................................................120Hz~10kHz
TEL IN SECTION (TEL IN@1kHz, PREAMP OUT)
Input Sensitivity/Impedance...............................................................................0.3V/600 Ω (USA/CANADA)
.................................................................................................................. 0.775V/600 Ω (EC & Associated)
Signal-to-Noise Ratio ...........................................................................................................Better than 65dB
Frequency Response (±3dB).......................................................................................................330Hz~3kHz
PRE AMP OUT (MIC 1~4, LINE 1~2, TEL IN, REMOTE IN)...............................................................0dBV/600 Ω
Total Harmonic Distortion ........................................................................................................Less than 0.5%
RECORD OUT ........................................................................................................................... –10dBV/3k Ω
- GENERAL
Power Source....................................................................100–120VAC or 220–240VAC; 50/60Hz, 24VDC
Power Consumption ......................................................................................PAM-510: 180W (1/8 POWER)
................................................................................................................... PAM-520: 320W (1/8 POWER)
Weight.....................................................................................................................PAM-510: 17kg/37.6lb
.................................................................................................................................. PAM-520: 19kg/42lb
Dimensions ...........................................................482(W) x 132(H) x 398(D)mm/19(W) x 5.2(H) x 15.7(D)in
Operating Temperature .............................................................................................................–10°C~40°C
* Specifications and design subject to change without notice.
