2/8 CHANNEL AUDIO TRANSMITTER/RECEIVER
3 FTA-108S/ITX-108/ITX-102, FRA-108S/IRX-108/IRX-102
Features Features Features
- TRANSMIT THE 2 CHANNEL AND 8 CHANNEL BALANCED AUDIO SIGNAL
2 Channel Model: ITX/IRX-102, 2 channel balanced audio signal transmission
8 Channel Model: FTA/FRA/ITX/IRX-108, 8 channel balanced audio signal transmission
- THE SOLUTION OF SENDING A SOUND SOURCE IN LONG DISTANCE
Optical Cable Communication [FTA/FRA-108S] : Sending a signal in long distance (maximum 15km)
UTP Cable Communication [ITX/IRX-108(102)] : Sending a signal in long distance (maximum 150m)
- HIGH QUALITY AUDIO SIGNAL
It sends the digital signal converted to 24Bit, 48kHz to provide the high quality audio signal
(higher than S/N 90dB, less than THD 0.01%)
- AC/DC SUPPORTS
It responses to the field conditions with supporting AC and DC power input terminals
- INPUT SENSITIVITY CONTROL FUNCTION THROUGH PAD SWITCHES
If it is clipped due to high input audio signal level, push the PAD switch to decrease the input signal in 10dB
- INPUT SIGNAL DISPLAY
Detects the audio signal and clip approved to each channel and display on the front panel.
- RS-232/RS-422/CONTACT POINT DATA RECEIVING/SENDING (OPTION MODULE)
The optional module (CT-100M/CR-100M) can be installed to make a possible to receive and send a RS-232,
RS-422 and 8 channel contact point data.
