15 PS-80 (FIXED-INSTALLATION 5" POWERED SPEAKER)
Specifications
pS-80
General Specifications
Type
FIXED-INSTALLATION, 5" POWERED SPEAKER
Frequency Range (-10dB) 60Hz~20kHz
Frequency Response (-3dB) 67Hz~20kHz
Sensitivity 88dB
Max. SPL 113.1dB
Coverage 120° conical
LF Driver 130 mm (5 in) driver with
50.8 mm (2 in) voice coil
HF Driver 25 mm (1 in) exit compression driver,
34.4 mm (1.35 in) voice coil
Horn/Waveguide Integral Conical Horn with HF
Enclosure 12T Birch Plywood
Fittings 2 Point for Bracket
Finish Textured black RoHS compliant paint
Grille Black powder coated
14 guage hexagon perforated steel,
protection mesh backing
Connection 3P EURO Block
Environmental Spec. Storage -20~70, ≤90%
Operating -10~40, ≤90%
Package AC Code Cable
3P Terminal EURO Block
Weight 4.29 kg / 9.45 lb
Shipping Weight 4.87 kg / 10.73 lb
Dimensions (WxHxD) 160 x 250 x 243 mm / 6.3 x 9.8 x 9.5 in
Shipping Dimensions (WxHxD) 303 x 322 x 215 mm / 11.9 x 12.7 x 8.5 in
Electronic Specifications
Type
Class - D
Output Power (@THD 1%) more than 170W
Input Sensitivity 4.5 dBu
S/N (use A-weighted filter) more than 95dB
Power 100-120VAC or 220-240VAC; 50/60Hz
(Supplied AC mains transformer depends on country requirements)
Power Consumption 21W
* Design and specification are subject to be changed for the improvement of product
quality without pre notice.
