15" SUBWOOFER SPEAKER
CLA-15S
FEATURES
Compact subbase system
Plywood enclosure of high density
The highest grade of subwoofer speakers are used to achieve the specific best of the sound
Integrated rigging system for suspending or ground stack with CLA-5
15"
SU
BW
OOF
ER S
PEA
KER
CLA-15S
TYPE
Compact 15" subwoofer
FREQUENCY RESPONSE(-10dB)
45? z-350Hz
TRANSDUCERS
15"woofer
POWER HANDLING
450W(AES) / 1800W(Peak)
SENSITIVITY(1W/1m)
98dB
MAXIMUM OUTPUT
131dB/1m
NORMINAL IMPEDANCE
8‰
CONNECTOR
2x NL4 in parallel, 1+/1-
ENCLOSURE MATERIAL
15mm plywood, black coat
RIGGING
Integral
WEIGHT(NET/SHIPPING)
20Kg / 22Kg
DIMENSIONS
562(W) x 510(D) x 520(H)mm
※ Dimension and performance are changeable depending on circumstances without notice.
SPECIFICATIONS
