13 PS-80 (FIXED-INSTALLATION 5" POWERED SPEAKER)
Connection
Cable connection
※CAUTION : The speaker is designed as fixed
installation, it doesn’t supply separate AC
power switch. For avoiding extra noise,
connect the audio cable first, and then
connect power cable with minimized
volume. Built-in Amp type speaker’s power
ON/OFF will be more efficiency using
Sequencial Power Supply like Inter-M’s
‘SPAC-660’. For reference, the speaker is
designed to be compensated low power
consumption, when audio signal doesn’t
exist.
Speaker should connect 2 cables for AC
output power and audio signal input. AC
power uses standard IEC connector, the
grounding type consent has to be used.
Audio signal input connector should use
with connecting balance audio signal
which is 3P euro block type.
Connecter
