Inter-M ECS-6216P User Manual
Page 11
11. AMP IN TERMINAL
Connects with output of AMP.
12. ADDRESS SWITCH
Sets the role for each system when equipment is expanded and linked.
Refer to Basic Setting and Checking (Page 4) for setting methods.
13. POWER INPUT TERMINAL
- Power input terminal. Check polarity before connecting DC 24V.
- When connecting to PD (Power Distributor), connect to unswitched terminal.
EMERGENCY COMBINATION SYSTEM
9
ECS-6216P/S
