Flannel (Canton) Buffs
These cotton buffs
are made with thicker,
softer fabric. Excellent
for final polishing
with rouge on precious
metals (especially
good on high karat gold and silver). Center
pin holes are reinforced with shellac (S) for
a tight fit on tapered mandrels.
Rows of Center Part
Dia. Ply Stitching Hole No.
3 ″ 30 2 S A-CFB3
Square Edge Solid Felt Buffs
Made from tightly com-
pressed, top quality
wool felt in medium
and hard density, these
are used for polishing
and lapping flat
surfaces. They hold an edge for working in
angles and corners, and have pin hole
centers for use on tapered mandrels. Use
with all compounds for cutting or polishing.
Small Diameter Buffs
These smaller diameter
buffs can be mounted on
mandrels for use in Foredom
Handpieces. The CBF1 can be
used with the M16. The other
buffs are suitable with M1,
M6, M7, M13, and M15
mandrels. Muslin buffs are
made from fine (80 x 80) weave muslin
for use with all types of compounds and
have shellac (S) reinforced center holes.
Felt buffs are made from wool felt.
Part
Dia. Thick Hardness No.
2 ″ 3/8 ″ Medium A-SE4M
Square Edge Felt Buffs
Part
Dia. Thick Hardness No.
1/2 ″ 1/8 ″ Medium A-SE1M
1/2 ″ 1/8 ″ Hard A-SE1H
5/8 ″ 3/16 ″ Medium A-FB4
3/4 ″ 1/8 ″ Medium A-SE2M
3/4 ″ 1/8 ″ Hard A-SE2H
3/4 ″ 1/4 ″ Medium A-FB3
1 ″ 1/8 ″ Medium A-SE3M
1 ″ 1/8 ″ Hard A-SE3H
Radial Bristle Discs
(shown above) for right side of lathe
3/8
″ Tapered Spindle Adapter A-4561
For left side of lathe use:
3/8 ″ Tapered Spindle Adapter A-4562
Also for right side of lathe:
A-CHA-5 Collet Holder
with 1/4
″ shank screw mandrels:
A-M31 or A-M31
All listed buffing and polishing accessories
are made in the USA.
wheels, regular brushes, and buffs, and
do not produce the heat associated with
rubber wheels. They work well on gold,
silver, platinum, brass, copper, titanium,
stainless steel, plastic, acrylic, and wood.
No compounds, rouges or pastes are
required. Bristles contain abrasives.
Part No. per 6-Pack
Grit Color 2 ″ Discs 3 ″ Discs
80 yellow A-4542-6 A-4552-6
120 white A-4543-6 A-4553-6
220 red A-4544-6 A-4554-6
400 blue A-4545-6 A-4555-6
pumice pink A-4546-6 A-4556-6
6micron peach A-4547-6 A-4557-6
1 micron lt.green A-4548-6 A-4558-6
These discs are popular among jewelers
and dental technicians because their thin
flexible bristles get into hard to reach areas.
Use for cleaning metal surfaces, fire scale
and oxide removal, finishing, blending,
texturing, pre-polishing and polishing,
Scotchbrite Radial Bristle Discs generate
little or no dust, last far longer than rubber
For 2 ″ discs
30,000 RPM Max Operating Speed
Recommended Speed for most
applications is 5,000–18,000 RPM
For 3 ″ discs
20,000 RPM Max Operating Speed
Recommended Speed for most
applications is 5,000–18,000 RPM
A-M30 and A-M31
Mandrels Mandrel with
ScotchBrite discs Collet Holder P/N:
A-CHA5
NEW! MAFH25 Filter Hood
Developed to work with Foredom’s Bench
Lathe, the Filter Hood is compact, powerful
and portable for use in jewelry making,
dental labs, or industry. It collects dust and
larger particles produced by light grinding
and polishing and can also be used with
other lathes, flex shafts or micromotors.
Cotton Buffs
Rows of Part
Dia. Thick Ply Stitching No.
1 ″ 3/16 ″ 16 2 A-CB2
1 ″ 3/8 ″ 40 2 A-CBF1
1 1 ⁄ 2
″ 3/16 ″ 16 3 A-CB12
• Strong suction removes hazardous dust and
filters precious metal for reclaiming
• Variable speed motor for 110 or 220 volt
• Heavy gauge steel construction
• CE compliant.
• Removable metal tray, gooseneck mounted
bright, LED light, polycarbonate shield.
• Comes with three filters – easy to change
and ship to a refiner.
• One Year Warranty
NEW
MAFH25
Filter Hood
