FOREDOM
®
P-DP70
Owner’s
Manual
For Your Own Safety:
Always wear eye protection.
Read this Owner’s Manual
before operating your
Foredom tool.
LIMITED WARRANTY
Foredom Electric Company warrants the P-DP70 Drill Press to be free of defects in material or
workmanship for a period of one year after purchase. During the warranty period, the defective
product will be repaired or replaced without charge or, at our option, the purchase price will be
refunded. This warranty does not cover damage caused in transit or by accident, misuse, or
ordinary wear.
ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO WARRANTIES OF FITNESS
AND MERCHANTABILITY, ARE HEREBY LIMITED IN DURATION TO A PERIOD ENDING ONE
YEAR FROM DATE OF PURCHASE, AND WE WILL NOT BE LIABLE OR RESPONSIBLE FOR
ANY SPECIAL OR CONSEQUENTIAL DAMAGES.
Repair or replacement will be made at our option if the product is returned post-paid to:
Foredom Electric Company
16 Stony Hill Road
Bethel, CT USA 06801
All warranty repairs must be done at the factory at the above address. We will not pay any
shipping or transportation charges. This warranty only covers the original purchaser of the
product. Some states do not allow limitations on how long an implied warranty lasts, so the
above limitations may not apply to you. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state.
FOREDOM
®
Foredom Electric Company
16 Stony Hill Road, Bethel, CT 06801
Tel.: 203-792-8622 • Fax: 203-796-7861
www.foredom.net
Form 1240 bh Printed in USA
Optional Accessories for the P-DP70 Drill Press:
Micro Chucks –
A-MC2
An accurate, economical adapter chuck, used for 60 to 80
wire gauge drills. The A-MC2 can be held in any 1/8 ″ collet.
A-M50
for use with drills #70-80
A-M52
Holds 1/16 ″ shank friction grip burs and has a
3/32 ″ shank.
Micro Chucks must be used at lower speeds:
A-MC2 10,000 RPM maximum speed
A-M50 10,000 RPM maximum speed
A-M52 20,000 RPM maximum speed
Drills - visit www.foredom.net to learn more about our
broad selection of diamond, steel and cobalt drills.
Collet Adapters –
This is not a collet. It is a ‘step down’ adapter that fits inside
a collet and allows the use of smaller shank size accessories
without having to actually change the collet. Use in H.MH-
170 micromotor handpiece (also for flexible shaft collet
style handpieces):
HPL4-3233
3/32 ″ to 1/16″
HPL4-3234 1/8 ″ to 1/16″
HPL4-3235 3.0mm to 3/32 ″
HPL4-3236 1/8 ″ to 3/32″
HPL4-3237 3.0mm to 1.6mm
For More Information:
For more information on Foredom
® equipment and acces-
sories, contact your local dealer. When no local dealer is
available, visit on line: www.foredom.net
Micromotor not included
