Victorian Lace DVS Face
Black 95200132
Page 1 of 1
11/5/07
© Travis Industries, Inc.
Compatibility
•
DVS Insert EF II
Packing List
•
Face
• Left and Right Bracket
•
(4) 10-24 Nuts
• (4) 1/4-20 Screws
Installation
Warning:
Make sure the heater has fully cooled prior to conducting service.
Install the face mounting brackets to
the heater with the included nuts.
NOTE: The brackets
install with this pair of
closely spaced
flanges at the top.
Use the screws included
with the face to secure the
face to the brackets.
32”
22-1/2”
WARNING: When attaching
the Victorian Lace Face, do
not over-tighten the screws.
Over-tightening the screws
may damage the face – simply
tighten the screws until they
contact the face.
