13
LP-04 REV. 4.15.14
Completely drain the water heater before removing and replacing the heating element. Failure to do so will result in a leakage of water
and property damage, and could possibly result in moderate to severe personal injury or death.
Water drained from the water heater may be scalding hot. Take care to avoid scalding. Wear gloves and safety glasses, and direct
water to a safe drainage location. Failure to comply with this warning could result in substantial property damage, severe personal
injury, or death due to scalds.
STEP #1
– Turn off power and remove wires from element.
Failure to disconnect power from water heater before attempting heating element replacement will result in property damage, severe
personal injury, or death due to electric shock.
DO NOT replace heating element with a generic heating element. Only HTP heating elements are approved for use with this water
heater. Failure to follow this warning will result in premature product failure and VOID the warranty.
STEP #2
– Remove the element with a 1 ½” socket
wrench.
STEP #3
– Ensure thread and opening are
completely free of debris.
STEP #4
– Put a small amount of NSF approved
pipe dope on the threads for lubrication.
STEP #5
– Screw the element clockwise into tank,
and tighten with the 1 ½” socket wrench. Be sure O-
ring seats properly.
STEP #6
– Refill the tank with cold water.
STEP #7
– Pressure check the tank for leaks
around element. If no leaks are found, reconnect
wires to the element.
STEP #8 - Turn power back on to the water heater.
Failure to refill the tank before restoring power to the water heater will result in damage to the heating element and property damage.
Such damages ARE NOT covered by warranty.
PART 6 – MAINTENANCE
MAINTENANCE CONSIDERATIONS

To avoid electric shock, disconnect electrical supply before performing maintenance.

To avoid severe burns, allow heater to cool before performing maintenance.
NOTE: In addition to the routine maintenance detailed in this manual, this water heater should be inspected annually by a qualified
service technician to assure that all the equipment is operating safely and efficiently. The owner should make necessary arrangements
with a qualified heating contractor for periodic maintenance of the heater. Installer must also inform the owner that lack of proper care
and maintenance may result in a hazardous condition, premature heater failure, and void the warranty.
Routine preventative maintenance ensures the water heater operates safely and efficiently over its service life. The Owner/User may
perform the maintenance activities described below.
Figure 7 – Heating Element Detail
