4 SUA48RMXLBP3U/SUA48RMXLBPJ3U External Battery Pack User Manual
Specifications
Specifications
Temperature
Operating
Storage
0° to 40° C (32° to 104° F)
-15° to 45° C (5° to 113° F) charge the battery module(s)
every six months
This unit is intended for indoor use
only. Select a location sturdy
enough to handle the weight.
Do not operate the UPS where
there is excessive dust or the
temperature or humidity are
outside the specified limits.
Be sure the air vents on the UPS
are not blocked.
Environmental factors impact
battery life. High temperatures,
poor utility power, and frequent,
short duration discharges will
shorten battery life.
Maximum
Elevation
Operating
Storage
3,000 m (10,000 ft)
15,240 m (50,000 ft)
Humidity 0 to 95% relative humidity, non-condensing
Weight 18 kg (40 lbs) without battery module
68 kg (150 lbs) with battery module
25 kg (55 lbs) each battery module 68 kg (150 lbs)
Dimensions
H x W x D
133 mm x 283 mm x 660 mm
5.24 in x 11.14 in x 26 in
Maximum Number of External Battery Packs Supported by the
Smart-UPS XL
10
Voltage 48 V
