FIRElink-25 – Installation Manual

Page 7 of 40

© 2010 Hochiki Europe (UK) Ltd

9-5-0-344/ISS4/OCT10

1.2 Inside the Detector

Removable terminal
blocks (see section 1.3)

Filter (see section 8)

Addressable
programmable interface
card (FIRElink-APIC)
port (see section 5.3)

Detector address DIP
switch (see section 5.1)

RS232 serial port (see
section 5.4)
