3 hook parts – Harrington Hoists and Cranes (N)ER Hoist - ((N)ER1) User Manual
Page 64
Fig No
Part Name
Parts Per
Hoist
001H 003S 005L 003H 005S 010L 010M 010S 015S 020L 020M 030C 020S 025S 030L 030S 050L
23
Body Protector
1
ER1FR-
9055
24
Socket Bolt
2
90912-
72
25
Spring Washer
2
90127-
11
26
Bottom Hook Complete Set
1
ER1BH-
1011
ER1BS-
1011
ER1CS-
1011
ER1CH-
1011
ER1CS-
1011
ER1DS1011
ER1DM-
1011
ER1ES1011
ER1DR
-1011
ER1ES-
1011
ER1EM-
1011
ER1FS1011
ER1FR-
1011
27
Bottom Hook Assembly
1
ER1FS
-2011
ER1FR-
2011
28 Hook Latch Assembly
1
ER1BS1002
ER1DS1002
ER1DM-
1002
ER1ES1002
ER1FS
1002
ER1ES-
1002
ER1FS1002
ER1FR-
1002
29
Thrust Collar A
1
ES026003
ES026010L
ES026015
ES026-
025
ES026-
015
ES026025
ES026-
050
30
Hook Stopper
2 ES027003
ES027010L
ES027015
ES027-
025
ES027-
015
ES027025
ES027-
050
31
Thrust Bearing
1
ES022003
ES022010L
ES022015
ES022-
025
ES022-
015
ES022025
ES022-
050
32
Bottom Shaft Assembly
1
ES5054-
030
ES5054-
050
33
Idle Sheave Assembly
1
ES1051-
030
ES1051-
050
34
Bottom Yoke Assembly
1
ES032-
030
ES032-
050
35 Bolt
3
ES082-
025
ES082-
050
36 Spring Washer
3
90127-
12
90127-
13
37 Nut
3
90934-
27
90934-
33
38
Name Plate C
1
M3805-
030
M3805-
030
39
Stopper Assembly
1 ER1CS1041
ER1DS1041
ER1ES1041
ER1ES1041
ER1FS1041
2
ER1ES
1041
ER1ES
1041
40
Load Chain (Black)
1
LCER003C
LCER005C
LCER010C
LCER020C
LCER-
025C
LCER030C
LCER-
025C
Load Chain (Nickel Plated)
1
LCER003NP
LCER005NP
LCER010NP
LCER020NP
LCER-
025NP
LCER030NP
LCER0
25NP
Load Chain (Nickel Diffused)
1
LCER003ND
LCER005ND
LCER010ND
LCER020ND
LCER-
025ND
LCER030ND
LCER-
025ND
10.3 Hook Parts
64
