9.7 Smart Limit Parts

Figure

No.

Part Name

Parts per

Hoist

Part Number

1

Photosensor Assembly

1

ER2BI1669

2

Spring Pin

1

ES451005S

3

Machine Screw with Spring
Washer

1

J1AP25000808

4

Smart Limit Label

1

80469

5

Micro-computer Assembly

1

ER2BEE00I5B7

6

Pan Head Machine Screw

1

J1AK23001515

7

Micro-computer Lead Wire

2

ER2BHE03I9B3

8

Transformer

1

2V

TRF32C912

4V

TRF92N912

9

Trigger Wheel

2

ER2BS9674

10

Socket Set Screw

1

J1TD1103008

11

Smart Limit Warning Tag

1

80476

12

Smart Limit Wiring Diagram

1

ER2BHE03I9B4


19
