www.skcltd.com 224-UMTXM Issue F Page 25
Universal MTX Pump Replacement Parts
Item Part No. Description Item Part No. Description
1 P22433C Keypad cover plate 8 P22417G Pump body
2 P22433RGY Cap screws (set of 2) 9 P22409
Inlet filter & O ring kit
(3 filters & 3 O rings)
3 P22433ES External screw pack 9 P2240901 Inlet filter (pack of 10)
4 P22419MTX Battery pack 4.8V 2.0Ah NiMH 10 P22417D
Filter housing assembly
(includes 1 inlet filter & 1 O ring)
5 P22433L Flow meter assembly 11 P22417K Pulsation dampener (set of 2)
6 P22417F Valve plate assembly (set of 2) 12 P22417J Regulator assembly
7 P22417H Yoke / diaphragm assembly 13 P22417C Pressure (exhaust) port fitting
SKC recommend that our air sampling pumps are regularly serviced by one of our Authorised Service Centres.
Due to the safety implications associated with the incorrect repair of ATEX certified intrinsically safe products
for use in potentially explosive atmospheres, it is our policy to only supply the complete range of replacement
parts to our Authorised Service Centres who are trained in the service and repair of these products.
The range of replacement parts listed above is available to all customers. If the required part is not listed,
contact SKC customer care on +44 (0) 1258 480188.
Note: Table item numbers correspond to the ringed numbers shown in the figures on page 24 of this manual.
