Care of the Battery Pack
Battery Testing
1. Connect SKC approved charger to battery pack. If charger indicator LED illuminates, battery pack charger
input is ok. If charger LED does not illuminate, battery pack input fuse is blown - Replace battery pack.
2. Leave battery pack connected to charger to fully charge.
3. If pump does not function at all after full charge of battery pack, battery pack output fuse has blown, or
battery cells have failed or are at end of life - Replace battery pack.
4. If pump functions after full charge of battery pack but gives significantly reduced run times before low
battery shutdown, battery cells are failing or are at end of life - Replace battery pack.
Battery Replacement
Refer to pump diagram on page 8. To remove the battery pack unscrew and remove the two battery screws
(No. 25). Carefully slide the battery pack sideways out from under the metal belt clip (No.22) and remove the
battery pack.
Fit the replacement battery by sliding it under the metal belt clip. Take care to ensure that the pins of the pump
power connector engage into the holes in the socket connector on the battery pack. Secure the battery pack
with the two screws.
Battery Disposal
• The EC Battery Directive and equivalent legislation in other countries requires that all batteries and battery
packs are disposed of correctly at the end of their working life. This means that they must be collected and
treated separately from other waste.
• Please ensure that any end-of-life SKC battery packs are collected and recycled or disposed of correctly.
