Getting Started
APPLICABLE TO MODEL 224-PCMTX8 ONLY
7) SET-UP Key (No. 4)
With the pump in hold mode, press the SET-UP key to enter setup mode. The LCD screen will show the legend
SET UP DELAYED START and the right hand digit will flash.
In the setup mode the delayed start time, sample time and run time can be entered.
8) MODE Key (No. 5)
With the pump in the setup mode press the MODE key to sequence through the DELAYED START, SAMPLE
PERIOD and PUMP PERIOD settings, indicated by the corresponding legends on the LCD screen. The function
of these three settings is explained in the section ‘Operating the Timer’ on pages 14 to 17.
The required values for these three settings can be entered using the DIGIT SELECT and DIGIT SET keys.
9) DIGIT SELECT key (No. 6)
With the pump in the setup mode and the required time setting selected, press the DIGIT SET key to cycle
through the four timer digits on the display. The currently selected digit is indicated by flashing on and off. When
the required digit is selected it can be set to the required value using the DIGIT SET key.
10) DIGIT SET key (No. 7)
With the pump in the setup mode, the required time setting selected and the required digit selected, press the
DIGIT SET key to increment the value of the digit from 0 to 9 and back to 0.
