SilverStone ST60F-ESB - Manual (Page 10)

09
SATA connector
Signal Pin
Orange +3.3V 5
Black COM 4
Red +5V 3
Black COM 2
Yellow +12V 1
Yellow
Black
Black
Red
Signal
+12V
COM
COM
+5VDC
Pin
1
2
3
4
Pin
1
2
3
4
Signal
+5VDC
COM
COM
+12V
Red
Black
Black
Yellow
4PIN peripheral connector (HDD) 4PIN floppy connector (FDD)
8PIN PCI Express connector
6PIN PCI Express connector
Signal Pin Pin Signal
Yellow +12V 1 5 COM Black
Yellow +12V 2 6 COM Black
Yellow +12V 3 7 COM Black
Black sense1 COM 4 8 COM Black
Signal Pin Pin Signal
Yellow +12V 1 4 COM Black
Yellow +12V 2 5 COM Black
Yellow +12V 3 6 COM Black
