6.4. GROUND LEAKAGE CURRENT

The power supply ground leakage current shall be less than 3.5 mA.

6.5. RELIABILITY

6.6. DIELECTRIC STRENGTH

The power supply reliability, when calculated by MIL-HDBK-217;latest revision,

are exceed 100,000 hours with all output at Typical load and an ambient

temperature of 25℃.

Primary to Frame Ground : 1800 Vac for 1 sec.

Primary to Secondary : 1800Vac for 1 sec

6.7. INSULATION RESISTANCE

Primary to Frame Ground : 20 Meg.ohms Minimum

Primary to Secondary : 20 Meg.ohms Minimum

7. MECHANICAL REQUIREMENTS

7.1 Physical Dimension

125 mm (W) × 63.5 mm (H) × 100mm (D)

7.2 Connectors

M/B 24PIN connector

Signal Pin Pin Signal

+3.3V

-12VDC

COM

PS-ON

COM
COM
COM

N/C

+5VDC
+5VDC
+5VDC

COM

+3.3V

COM

+5VDC

COM

+5VDC

COM

PWRGOOD

+5Vsb

+12V
+12V

+3.3V

Orange
Blue
Black
Green
Black
Black
Black
White
Red
Red
Red
Black

Orange
Orange
Black
Red
Black
Red
Black
Grey
Purple
Yellow
Yellow
Black

13
14
15
16
17
18
19
20
21
22
23
24

1
2
3
4
5
6
7
8
9
