4 . OUTPUT ELECTRICAL REQUIREMENTS
4.1. OUTPUT VOLTAGE AND CURRENT RATING
+3.3V 0.1A 10.5A 21A ±5% ±1% 50mV P-P
+5V 0.2A 10A 20A ±5% ±1% 50mV P-P
+12V 0.5A 8A 22A ±5% ±1% 120mV P-P
-12V 0A 0.25A 0.5A ±10% ±1% 120mV P-P
+5VSB 0A 1.25A 2.5A 3A ±5% ±1% 50mV P-P
MINIMUM
LOAD
NORMAL
LOAD
MAXIMUM
LOAD
PEAK
LOAD
LOAD
REG
LINE
REG
RIPPLE & NOISE
( 1 ) +3.3V & 5V total output not exceed 103W.
( 2 ) Total output continuous shall not exceed 300W watts.
( 3 )+5Vsb peak current is 3A(less then 500m sec.) , minimum voltage during peak is > 4.5Vdc.
( 4 )Voltages and ripple are measured at the load side of mating connectors with a 0.1 uF
monolithic ceramic capacitor paralleled by a 10 uF electrolytic capacitor across the measuring terminals.
The cross regulation defined as follows, the voltage regulation limits DC include
DC Output ripple & noise.
LOAD +3.3V +5V +12V -12V +5VSB
Output
condition_1
condition_2
condition_3
condition_4
condition_5
condition_6
condition_7
condition_8
CL-Test-1
CL-Test-2
CL-Test-3
CL-Test-4
X
0.1A
1.5A
1A
1A
0.9A
18A
21A
12.4A
12.4A
1A
0.6A
X
1.5A
0.2A
10A
14A
20A
2A
6.74A
12.4A
12A
1A
0.6A
X
0.6A
0.6A
16A
4A
15.7A
2A
15.7A
1A
0.8A
22A
22A
X
0A
0.5A
0.1A
0.1A
0.3A
0A
0.3A
0.1A
0.1A
0.1A
0.1A
2.5A
0A
0A
0.1A
0.1A
1A
0.1A
1A
0.1A
0.1A
0.1A
0.1A
4.2. LOAD CAPACITY SPECIFICATIONS
