Connection Cables
i
MON OEM Touch LCD
H/W and S/W Installation Guide
D-SUB 15P M/M CABLE
USB CABLE
IR receiver connection
4-PIN/DC POWER CABLE
FRONT PANEL CONTROL CABLE
Touch LCD Hardeare Installation
For hardware installation, please connect each cables as below.
D-SUB 15P M/M CABLE
USB CABLE
4-PIN/DC POWER CABLE
