SecurityMan MirrorCam - Manual (Page 12)

12
Related Product:
It is recommended to consider using SecurityMan’s
SM-401 for easy wireless installation. The SM-401 is a
wireless converter that convert wired camera to wireless
For detail information on SM-401 go to:
http://www.securitymaninc.com/product/sm_401.html
Product Specifications:
Image Sensor
1/3” SHARP CCD,
color
Lens
CS mount f= 4.0 mm /
F=1.2
Effective Pixels 512×492(NTSC) Scanning System
2:1 Interlace, V: 60Hz, H:
15,750KHz
Resolution
420 TV Line
(Horizontal)
Gamma
Correction / S/N
Ratio
R>0.45 / 48 dB, AGC off
Video Output
1 Vp-p Composit
Output (BNC), 75
ohms
Viewing Angle Horizontal 65°
Sync. System Internal Sync.
Operating
Temperature
-10℃ to
50℃(+14ºF~+122ºF)/
‹80%RH
Shutter Control
Auto: 1/60 to
1/100,000 Sec.
Dimension
60 (D) x 218 (Ø) mm
2.36”(D) x 8.5” (Ø)
Minimum
Illumination
0.3 Lux / F-2.0
Power
Consumption
110 mA (Max.)
White Balance
& Gain Control
Auto Power 12VDC 1.0A (+ inside)
