15
C) Setting up the Camera
1) Place the camera at desired location.
2) Plug the power adapter or battery clip jack into the power jack at the
back of the camera.
3) Plug the power adapter to any DC outlet or plug a 9V battery to the
battery clip.
4) Check the Camera Frequency number of each camera at the back.
(The receiver will receive signal from camera’s corresponding fre-
quency and display in different channels. For example, Channel 1
on the TV/Monitor will display the picture from Camera 1 only).
D) Setting up the Receiver to match camera’s frequency
Press the Channel Switch button until the LED channel indicator light
match to the camera’s frequency (Camera frequency can be found at the
back of the camera).
CH4 CH3 CH2 CH1 SET
LED channel Indicator
Channel Switch
1
ZT-809T CMOS DC8V 2.4GHz
NTSC
Power Jack
Camera
Frequency
Camera Back
