Dimensions – A.O. Smith BFM - 120 User Manual
Page 3
BFM
Dimensions
A 2000
2000
2020
2020
2020
B 1800
1800
1820
1820
1820
C 580
580
580
580
580
D 710
710
710
710
710
E 1000
1000
1000
1000
1000
F 755
755
755
755
755
G 125
125
150
200
130
Hy -
-
-
235
235
K 600
600
600
600
760
L 125
150
200
130
130
M 600
600
590
590
590
N 1640
1640
1655
1655
1655
P 770
770
760
760
760
R 550
550
540
540
540
S 1600
1600
1600
1600
1600
1
Cold water (external)
R1
1
/
2
2
Hot water (internal)
Rp1
1
/
2
3
Gas control (internal)
Rp
3
/
4
(BFM120 = Rp1)
4
Tank drain valve (internal)
R1
1
/
2
5
T&P valve (internal)
1-11.5 NPT (BFM 30-50)
Rp1
1
/
2
(BFM 80-120)
6
Cleaning and inspection opening
Ø100
Dimensions in mm. All BFM water heaters receive a three years
warranty on the tank and one year on parts.
BFM 30
BFM 50
BFM 80
BFM 100
BFM 120
BFM 30-80
BFM 100-120
