GB - 22
Wheel drive
does not
engage (Self-
Propelled
models) 1. Wheel drive control not
engaged.
2. Drive belt out of position.
3. Drive belt worn or damaged.
4. Rear wheels in different
cutting heights.
5. Idler spring detached.
6. Wheel drive control cable
detached or broken.
7. Friction disc not adjusted
properly or damaged.
8. Bearings damaged.
9. Debris in gear set.
1. Engage wheel drive control.
2. Check drive belt. Adjust as
necessary (see Check Drive
Belt (self-propelled models)
on page 16).
3. Replace belt (see Check
Drive Belt (self-propelled
models) on page 16).
4. Adjust rear wheels to same
cutting height (see Cutting
Height Adjustment on
page 11).
5. Attach idler spring to notch
on idler arm. Contact your
Dealer.
6. Check wheel drive control
cable. Adjust or replace as
needed. See Check Wheel
Drive Control (self-propelled
models) on page 15.
7. Contact your Dealer.
8. Contact your Dealer.
9. Contact your Dealer.
PROBLEM PROBABLE CAUSE CORRECTION
SERVICE PARTS
Always use genuine Gravely parts to keep
your mower running like new.
Description Part Number
Air Filter 08270501 (911094, 095, 394)
21535600 (911098, 100)
Spark Plug 08270502 (911094, 095, 394)
21534100 (911098, 100)
Blade 01137000 (Standard)
01182400 (Tungsten)
Drive Belt 07217100 (094, 911098, 100)
Friction
Disc 03248300 (911094)
51102500 (911098, 100)
ACCESSORIES
See your authorized Gravely Dealer to add
these optional accessories.
71102400 Dethatcher
71102700 Mulchmaster Plug
71103000 Grass Bag
71103200 Rear Discharge Chute
71103500 Mulchmaster Mulching Kit
71103700 Leaf Shredder
71104100 Front Swivel Wheel Kit
71104700 Bag-N-Drag Bagger Kit
