Robinair Model 15505 - Manual (Page 8)

6
Service Parts
Part No. Description
523192 Handle and Switch Assembly (all models except 15800)
535491 Handle and Switch Assembly (Model 15800)
523193 Oil Drain Fitting
523194 Capacitor (all models except 15800)
535492 Capacitor (Model 15800)
523195 Oil Fill Plug
523197 Base (all models except 15800)
535493 Base (Model 15800)
523199 Housing Gasket (Models 15150, 15151, and 15155)
523201 Housing Gasket (Models 15300, 15301, 15355, 15500, 15501, 15505, 15203)
535494 Housing Gasket (Model 15800)
523203 Exhaust Fitting (all models except 15800)
535495 Exhaust Fitting (Model 15800)
523208 Inlet Fitting Adapter, 3/8" Male Flare x 1/2" Female ACME
525402 Inlet Fitting, 1/4" and 3/8" Male Flare
525488 Inlet Fitting Adapter, 3/8" Female Flare x 1/2" Male ACME
Exhaust
Fitting
Oil Fill
Plug
Inlet Fitting
Handle and
Switch Assembly
Oil Drain Fitting
(not shown)
Capacitor
(under handle)
Housing Gasket
(not shown)
Base
