Robinair Model 15505 - Manual (Page 2)

Questionnaire
High Performance Vacuum Pump
We appreciate your answers to these questions which
will assist us in meeting your future product and service
needs. Thank you.
1. What type of service work do you perform?
___% Automotive ___% Residential
___% Commercial A/C ___% Refrigeration
2. What influenced your decision to buy Robinair?
q
Advertising
q Literature / Brochure
q
Distributor Display / Promotion
q
Friend’s Recommendation
q
Distributor’s Recommendation
q Previous Satisfaction with Robinair Product(s)
q
Robinair Reputation
q
Warranty Coverage
q
Product Availability
q
After-Sale Service
q Other (please explain)
3. If this is a replacement pump, what brand does
it replace?
4. Do you own any other Robinair equipment?
q Yes q No
If yes, check the Robinair items you own:
q
Refrigerant Recovery / Recycling Equipment
q Manifold Gauge Set q Tubing Tools
q
Dial-A-Charge ® q
Charging Hoses
q
Fittings and Valves
q
Test Equipment
q Thermistor q Leak Detector
Vacuum Gauge
q
Other (explain)
5. Do you curently own refrigerant recovery and
recycling equipment?
q
Yes
q
No
If no, are you considering buying this type of
equipment in the future?
q
Yes
q
No
WARNING! To prevent personal injury,
Wear goggles when working with refrigerants. Contact with
refrigerants may cause injury.
Incorrect use or connections may cause electrical shock hazards.
Read and follow the instructions carefully, and take precautions to
avoid electrical shock hazards. Confirm that all associated devices
are grounded correctly before energizing circuits.
Normal operating temperature will cause certain external portions of
the pump to be hot to the touch. Do not touch the pump housing or
motor during operation.
SAFETY PRECAUTIONS
For use on A/C-R systems using CFCs, HCFCs, and HFCs in conjunction
with mineral oil, ester oil, alkylbenzene oil, and PAG oil as lubricants.
Not for use with ammonia or lithium bromide systems. Not for use with
flammable refrigerants.
WARRANTY REGISTRATION CARD
IMPORTANT: Complete this card and return it within 10 days from date of purchase in order to
validate the warranty. See your distributor for complete warranty details.
Model No. Serial No. Date of Purchase
Purchaser’s Name
Business Name Telephone:
Address
City State Zip Code
Email Address
Purchased From
Address
City State Zip Code
FOLD ON LINE AND TAPE TO SEAL. DO NOT STAPLE.
VacuMaster
®
2-Stage Pump Specifications
15150 15300 15500 15800
Voltage 115V / 60 Hz 115V / 60 Hz 115V / 60 Hz 120V / 60 Hz
Free Air Displacement 1.5 CFM 3 CFM 5 CFM 8 CFM
Ultimate Vacuum 50 microns 40 microns 40 microns 40 microns
Stages 2 2 2 2
Motor 1/4 HP 1/3 HP 1/3 HP 1 HP
Intake Ports
1 / 4" & 3 / 8" Flare, 1 / 4" & 3 / 8" Flare, 1 / 4" & 3 / 8" Flare, 1 / 4" & 3 / 8" Flare,
1 / 2" ACME 1 / 2" ACME 1 / 2" ACME 1 / 2" ACME
Oil Capacity 7.4 oz. 7.4 oz. 7.4 oz. 18.6 oz.
Power Cord Length 6 ft. 6 ft. 6 ft. 6 ft.
Dimensions (in.) 12.5 x 4.75 x 9.5 13.25 x 5 x 10 13.25 x 5 x 10 15.5 x 5.75 x 10.25
Net Weight 22 lbs. 28 lbs. 28 lbs. 38 lbs.
15151 / 15155 15301 / 15355 15501 / 15505
Voltage (220V) 50 Hz / 60 Hz 50 Hz / 60 Hz 50 Hz / 60 Hz
Free Air Displacement 35 lpm / 1.5 CFM 71 lpm / 3 CFM 118 lpm / 5 CFM
Ultimate Vacuum 50 microns 40 microns 40 microns
Stages 2 2 2
Motor 1/4 HP 1/3 HP 1/3 HP
Intake Ports
1 / 4" & 3 / 8" Flare, 1 / 4" & 3 / 8" Flare, 1 / 4" & 3 / 8" Flare,
1 / 2" ACME 1 / 2" ACME 1 / 2" ACME
Oil Capacity 220 ml 220 ml 220 ml
Power Cord Length 1.82 m 1.82 m 1.82 m
Dimensions (mm) 315 x 120 x 240 336 x 123 x 255 336 x 123 x 255
Net Weight 9.6 kg 12.5 kg 12.5 kg
15203
Voltage 100V / 50–60 Hz
Free Air Displacement
85 lpm @ 60 Hz
71 lpm @ 50 Hz
Ultimate Vacuum 40 microns
Stages 2
Motor 1/3 HP
Intake Ports
1 / 4" & 3 / 8" Flare,
1 / 2" ACME
Oil Capacity 220 ml
Power Cord Length 1.82 m
Dimensions (mm) 336 x 123 x 255
Net Weight 12.5 kg
