Rivers Edge RE722 5' EXT FOR DOUBLE RUNG CLIMBING AID - Manual (Page 13)

Check for parts online at www.huntriversedge.com or call 800-450-EDGE (3343) M-F 8-5 13
Operator's Manual
Rivers Edge Climbing Aids
SET-UP AND USE INSTRUCTIONS
1. Stand the stick up against the selected straight tree on dry, level
ground. Take the snap hook end of the bottom section strap,
wrap it around the tree, and attach it to the opposite slot of strap
bracket by snapping it into the slot. Pull the tail of cam strap tight
so that the section is snugly secured to the tree. SEE FIGURE 4. Be
certain (2) two contact points of the tree hugger are contacting
the tree.
2. While properly wearing/using a Full Body Harness with a lineman’s/
climbing belt, climb the assembled climbing aid only far enough to
reach the middle section strap and attach it to the tree. Repeat step 1
for proper attachment.
3. Repeat steps 1 and 2 for strap attachment for each section until all
sections are securely attached.
4. Reverse set-up and use instructions to take down climbing aid.
Figure 4
WARNING
BE CERTAIN SPRING LOCK PINS ARE LATCHED SE-
CURELY TO PREVENT ACCIDENTAL REMOVAL.
ALWAYS HAVE STEPS FOLDED DOWN TO THE IN-USE
POSITION DURING USE.
