Ransburg Overhead Electric Reciprocator ER-8100 - Manual (Page 43)

1 M-1021 Motor House 1
2 M-1000 Limit Switch W/Arm 1
3 M-1050 6” Short Hard Stop 1
4 M-1022 Triple Chain Attachment Block 2
5 M-1023 6” Counter Balance Tube 1
6 -- -- --
7 M-1024-XXX Triple Chain Assembly W/Cams 1
8 M-1025 Lower Limit Cams 1
9 M-1026 Counter Balance Guides 16
10 M-1027-XXX Counter Balance Assembly 1
11 M-1028 Gusset 4
12 M-1029 Base Plate 1
13 M-1030 Bottom Cover 1
14 M-1031 Disk Mounting Stud 1
15 M-1032 Motor and Gear Box Assembly 1
15A M-1050 24 VDC Brake 1
15B M-1051 Encoder 1
16 M-1033 Triple Chain Sprocket 1
17 M-1000 Limit Switch W/Arm 1
18 M-1000 Limit Switch W/Arm 1
19 M-1034 “Upper Limit” Cams 6
20 M-1035 Friction Brake Assembly 1
21 M-1001-XXX 10” Outer Tube 1
22 M-1002-XXX 6” Telescoping Tube 1
23 M-1036 Counter Balance Door 6
Item #
ELECTRIC RECIPROCATOR ASSEMBLY (ELEVATION VIEW) - PARTS
LIST (Figure 19)
Part # Description Qty
40
Electric Overhead Reciprocator - Parts Identification
Ransburg
LN-9801-05.1
