Lumastream - analog control options revc.pdf, Wir-ana-001 b – LumaStream ANALOG - INTELLIGENT POWER CENTER User Manual
Page 2
Low voltage toggle
switches and/or
0-10V analog dimmers
Note: For the UP position to be ON, toggle switches must be installed upside down.
When switch is closed, LED’s are OFF.
GROUND (GREEN)
NEUT (WHITE)
LINE (BLACK)
AC MAINS
REV:
DWG #:
TITLE:
INDEPENDENT ZONE CONTROL USING
SWITCHES AND/OR 0-10V DIMMERS
WIR-ANA-001
B
ZONE 4
ZONE 3
ZONE 2
ZONE 1
18/2 MULTICONDUCTOR CABLE
LED
LED
LED
LED
LED
LED
24 LED FIXTURES
ZONE1
ZONE2
ZONE3
ZONE4
LED
LED
LED
LED
LED
LED
LED
LED
LED
LED
LED
LED
LED
LED
LED
LED
LED
LED
B3
BREAKOUT
MODULE
B3
BREAKOUT
MODULE
B6
BREAKOUT
MODULE
GRAY
GRAY
GRAY
GRAY
VIOLET
VIOLET
