Bradley Stand-On Hydro Drive Mower Parts List
33
36”
48”
&
52”
R
EAR
D
ECK
A
SSEMBLY
I
TEM
P
ART
N
UMBER
D
ESCRIPTION
Q
TY
1 N/A
Engine
Assembly
1
2
300-059
Oil Drain Tube
1
3 300-060
Nylon
Washer
2
4
300-061
Hexagon Bolt M14x1.5x20
1
5
200-048
Hexagon Bolt M8x20 GB5783-86
1
6 300-062
Pipe
Clamp
1
7 300-063
Fitting
1
8 336-155
Transmission
Belt
1
9
200-006
Nylon Nut M10 GB889-86
4
10
200-010
Plain Washer 10 GB95-85
4
11
200-031
Lock Washer 10 GB93-87
4
12
200-019
Hexagon Bolt M10x40 GB5782-86
4
13 100-099
Spacer
6.5
1
14 300-067
Key
6.35x6x68
1
15 300-065
Pulley,
Input
1
16 300-066
Pulley,
Single
1
17
100-118
Plain Washer 3x12idx38xod
1
18
200-050
Bolt 7/16-20, Engine
1
