Havener T-Style Stand-On Mower 36, 48 & 52 User Manual
Page 31
Bradley Stand-On Hydro Drive Mower Parts List
31
36”
48”
&
52”
H
ANDLE
C
ONTROL
A
SSEMBLY
I
TEM
P
ART
N
UMBER
D
ESCRIPTION
Q
TY
1 336-200
RH
Control
Frame
1
2 200-020 Hexagon Bolt M10x70 GB5782-86
2
3
200-010
Plain Washer 10 GB95-85
8
4 336-121
Parking Brake Lever Support Sleeve
2
5 200-006
Nylon Nut M10 GB889-86
30
6 300-015B
Rod
End
RH8
1
7 200-069
Hair
Pin
Cotter
2
8
200-021
Plain Washer 8 GB95-85
4
9 200-025 Hexagon Bolt M8x30 GB5783-86
1
10 336-120
Parking Brake Handle
1
11 100-045
Flat
Grip
2
12 336-201
Swivel
2
13
336-202
Lever Shaft Bushing
4
14
336-203
LH Control Lever
1
15 336-204
Handle
Grip
1
16
700-098
Control Lever Grip
2
17 700-137A
Ignition Switch Nut
1
18
200-202
Bolt M5x16 GB5789
2
19 336-149
Throttle
Cable
1
20 100-091
Throttle
Control
1
21 336-205
Dash
Panel
1
22 700-
137
Ignition Switch
1
23 336-206
RH
Control
Lever
1
24 200-013
Nylon Nut M5 GB889-86
4
25 336-207
Handle
Bar
1
26 336-208
Dash
Panel
Weldment
1
27 200-203
Nut
Flange M6 GB6187-86
4
28
200-204
Mushroom Head Square Neck Bolts
2
29 336-162
Switch
1
30
200-200
Phillips Pan Head Screws M5x20
2
31 200-205
Nylon Self-Locking Flange Surface Nut
2
32 336-209
Spring
1
33 200-009
Nylon Nut M6 GB889-86
1
34 200-044 Hexagon Bolt M6x40 GB5782-86
1
35 336-210 RH
Operating Handrail Weldment 1
36 200-052 Hexagon Bolt M10x45 GB5782-86
1
37 200-003 Hexagon Bolt M10x25 GB5783-86
26
38
200-031
Lock Washer 10 GB93-87
4
39
366-211
Handle Shaft Weldment
1
40 200-048 Hexagon Bolt M8x20 GB5783-86
1
41 336-212
Leaning Pad Plate
1
42 200-206 Hexagon Bolt M6x40 GB5783-86
2
43 200-018 Hexagon Xolt M10x35 GB5783-87
4
44 336-103
Leaning Pad
1
45
336-170
Blade Control Handle
1
46 300-015A Rod
End
RH10
1
47 200-207 Hexagon Bolt M10x40 GB5783-86
1
48
200-201
Nut M10 GB6170
4
49
336-213
LH Control Frame
1
50
336-214
Blade Control Rod
1
51
336-215
Fuel Tank Supporting Plate
1
52 336-216
Direction
Control
Lever
2
53
200-208
Nut M8 GB6170
2
54 336-217
Parking Brake Control Lever
1
55 200-030
Nylon Nut M8 GB889-86
2
