Bradley Stand-On Hydro Drive Mower Parts List
29
36”
48”
&
52”
B
RAKE AND
W
HEEL
A
SSEMBLY
I
TEM
P
ART
N
UMBER
D
ESCRIPTION
Q
TY
1 200-076
Nut
1/2-20
8
2
336-106
Tire and Wheel Assembly
2
3
200-006
Nylon Nut M10 GB889-86
3
4
300-024
Neutral Handle Knob
1
5 336-107
Neutral
Handle
1
6
200-024
Lock Washer 8 GB93-87
12
7
200-021
Plain Washer 8 GB95-85
12
8
200-188
Hexagon Bolt M10x75 GB5782
8
9
200-189
Square Neck Bolt M8x35 GB801
4
10
200-030
Nylon Nut M8 GB889-86
16
11
336-109
Hydraulic Motor Support Plate
2
12
200-108
Hexagon Bolt M8x60 GB5782
2
13
200-098
Plain washer 8 GB96
14
14
336-110
Right Side Neutral Linkage
1
15
336-111
Flexible cylindrical pin 3X16
2
16 300-012
Neutral
Spring
2
17 336-112
Reverse
linkage
2
18
336-113
Left Side Neutral Linkage
1
19
336-114
Neutral Lever Weldment
1
20
200-069
Hair Pin Cotter
6
21 300-009
Threaded
Tube
1
22
200-071
Plain Washer 12 GB95-85
1
23
200-078
Lock Washer 12 GB93-87
1
24
200-004
Hexagon Bolt M12x25 GB5783-86
1
25
200-018
Hexagon Bolt M10x35 GB5783-86
2
26
200-190
Hexagon bolt M10x20 GB5783
2
27
200-010
Plain Washer 10 GB95-85
2
28
300-015A
Rod End RH10
2
29
336-117A
Right Transmission Bracket
1
30
336-116
Right Side Hydro Drive
1
31
200-075
Hexagon Bolt M8x65 GB5782-86
2
32
336-117B
Left Transmission Bracket
1
33
336-118
Left side Hydro Drive
1
