Havener Pistol-Grip Hydro Walk-Behind Mower 36, 48 & 52 User Manual
Page 39
14
36”, 48” & 52” Handle Control Assembly
Item No.
Part Number
Description
Qty
1
100-084
OPC Lever RH
1
2
100-085
OPC Lever LH
1
3
100-083
Flange Bushing
4
4
200-013
Nylon Nut M5 GB889-86
2
5
100-091
Throttle Control
1
6
200-012
Bolt M5*20 GB5781-85
2
7
200-055
Hexagon Bolt M6*50 GB5782-86
2
8
300-085
Traction Lock with Grip LH
1
9
300-086
Traction Lock with Grip, RH
1
10
100-087
Bushing, Traction Lock
2
11
200-010
Plain Washer 10 GB95-85
4
12
100-072
Handle Grip
2
13
200-051
Nut M6 GB923-86
2
14
100-076
Roll Pin
4
15
100-073
Traction Control Lever
2
16
100-075
Clevis Pin Traction Control Lever
2
17
100-077
OPC Spring
2
18
300-068
Traction Rod
2
19
100-086
Clevis Pin OPC lever
2
20
200-014
Cotter Pin 2*20 GB91-86
3
21
300-069
Top Handle Weldment
1
22
100-018
Swivel 2
23
200-069
Hair Pin Cotter
4
24
200-006
Nylon Nut M10 GB889-86
4
25
200-103
Hexagon Bolt M10*30 GB5783-86
4
26
300-070
Compression Spring
2
27
200-021
Plain Washer 8 GB95-85
7
28
200-030
Nylon Nut M8 GB889-86
2
29
200-011
Bolt M6*16 GB/T794-93
2
30
300-071
Lead Board
1
31
300-072
Nylon Washer
2
32
300-073
Ball Handle
1
33
300-074
Speed Rod
1
34
200-009
Nylon Nut M6 GB889-86
2
35
200-079
Hexagon Bolt M8*50 GB5782-86
2
36
300-075
Blade Rod
1
37
200-074
Nut M8 GB6170-86
2
38
300-007
Free Bar
2
39
300-003
Clevis Pin
1
40
200-073
Snap Ring 14 GB894- 1-86
1
41
300-076
Nylon Pivot
1
42
300-077
Blade Rod
2
43
100-125
Small Handle Grip
2
44
300-078
Pull Handle
1
45
300-079
Blade Decal
1
46
100-126
Name Plate
1
47
300-080
Hydro Drive Decal
1
48
300-081
Operating Control Decal
1
49
300-089
Traction Control Lever Grip
2
