36”, 48” & 52” Rear Deck Assembly
Item No.
Part Number
Description
Qty
1
N/A
Engine Assembly
1
2
200-029
Nut Flange M8 GB187-86
2
3
300-059
Discharge Oil Pipe
1
4
300-060
Nylon Washer
2
5
300-061
Hexagon Bolt M14*1.5*20GB
1
6
200-105
Hexagon Bolt M8*80GB5783-86
1
7
300-062
Pipe Clamp
1
8
300-063
Fitting
1
10
300-130
Transmission Belt
1
11
200-025
Hexagon Bolt M8*30GB5783-86
4
12
100-099
Spacer 6.5
1
13
300-065
Pulley, Input
1
14
300-066
Puley, Single
1
15
100-118
Plain Washer 3*12id*38od
1
16
200-050
Bolt 7/16-20, Engine
1
17
300-067
Key 6.35*6*68
2
18
200-024
Lock Washer 8 GB93-87
4
