Havener Pistol-Grip Hydro Walk-Behind Mower 36, 48 & 52 User Manual
Page 33
8
36”, 48” & 52” Brake & Wheel Assembly
Item No.
Part Number
Description
Qty
1
200-004
Hexagon Bolt M12*25GB5783-86
1
2
200-071
Plain Washer
2
3
300-009
Tube with Thread
1
4
300-010
Neutral Lever Weldment
1
5
300-011
Neutral Handle
1
6
200-010
Plain Washer 10 GB95-85
1
7
200-003
Hexagon Bolt M10*25GB5783-86
4
8
200-014
Cotter Pin 2*20 GB91-86
2
9
300-012
Neutral Spring
2
10
300-013
Crank Shank
2
11
200-029
Nut Flange M8 GB187-86
12
12
300-014
Belt Guide Weldment
1
13
200-074
Hexagon Nut M8 GB6170-86
2
14
200-075
Hexagon Bolt M8*65GB5782-86
4
15
200-025
Hexagon Bolt M8*30GB5783-86
2
16
300-015
Rod End RH 8
2
17
200-078
Lock Washer 12 GB93-87
2
18
300-016
Turn Buckle Rod
2
19
300-017
Link Plank
1
20
300-018
Rod End LH 8
2
21
200-030
Nylon Nut M8 GB889-86
4
22
300-019
Tire and Wheel Assembly
2
23
200-021
Plain Washer 8 GB95-85
8
24
200-076
Nut 1/2-20
8
25
N/A
Hydro-Gear Assembly
2
26
300-021
Park Rod
1
27
200-016
Nut flange M10 GB6187-86
4
28
200-069
Hair Pin Cotter
5
29
200-077
Hexagon Bolt M8*80GB5782-86
2
30
300-022
Pump Cover
1
31
300-023
Park Lever
1
32
300-024
Shifter Knob
1
33
200-072
Hexagon Bolt M6*20GB5783-86
2
34
300-025
Park Support Brake
1
35
200-009
Nylon Nut M6 GB889-86
2
36
300-026
Revert Spring
2
37
300-027
Space 13
4
38
200-031
Lock Washer 10 GB93-87
1
39
300-028
Reverse Link
2
40
300-029
Plank
1
41
300-030
Straight Pivot
1
42
300-031
Spring
1
43
200-006
Nylon Nut M10 GB889-86
2
44
300-090
Air Breather Cap
2
45
300-087
Air Breather Tube
2
46
200-100
O Seal Ring 13.2*2.65 G
3
47
300-088
Pipe Seat
2
48
200-101
Hexagon Bolt M6*6 GB5780
2
49
200-102
O Seal Ring 6*1.8 G
2
50
300-091
Tube Screw
2
51
200-080
Hexagon Nut M8 L GB170-86
2
52
200-104
Hexagon Bolt M8*65 GB5782-86
6
53
200-108
Hexagon Bolt M10*35 GB5783-86
1
