GENERAL PUMP
A member of the Interpump Group
VS SERIES
Page 16
REPAIR KITS
Item VS16 VS18 VS20 VS22 VS24
66-72-73-75-77-79-80-81-98-99 F1277 F1278 F1279 F1280 F1281
85-87-98-99 F1117
2-13-14-17-22-28-32-34-35-37-40
42-46-49-54-60-62-63-66-72-73
75-77-79-80-81-85-87-93-98-99
F1282 F1283 F1284 F1285 F1286
Item Part # Description QTY.
1 F060100460 Gear box housing 1
2 F872047005 Washer Ø 10 8
3 F871125108 Screw M10 x 40 8
4 F052000100 Gear 1500 RPM (Z55) 1
F052000120 Gear 1800 RPM (Z58) 1
F052000280 Gear 2200 RPM (Z67) 1
5 F030000090 Gear retainer flange 1
6 F871125105 Screw M10 x 25 3
7 F872126004 Retainer pin Ø 12 x 40 2
8 F871125110 Screw M10 x 50 7
9 F010100100 Hydraulic motor flange 1
10 F871125154 Screw M10 x 30 8-14-16
11 F871125153 Screw M10 x 25 3
12 F063100190 Gear box flange 1
13 F881010131 O-ring Ø 113.97 x 2.62 1
14 F881080026 Oil seal Ø 55 x 75 x 10 1
15 F871110010 Bearing 1
16 F063100150 Gear box cover 1
17 F080600140 Gear box gasket 1
18 F872097009 Pinion key 1
F872097013 Pinion key (pinion Ø 48) 1
19 F052000110 Pinion 1500 RPM (Z27) 1
F052000130 Pinion 1800 RPM (Z24) 1
F052000180 Pinion 1500 RPM (Z27) Ø 48 1
F052000210 Pinion 1800 RPM (Z24) Ø 48 1
F052000270 Pinion 2200 RPM (Z22) 1
F052000300 Pinion 2200 RPM (Z22) Ø 48 1
20 F871110002 Bearing 1
21 F812000001 Brass bearing 3
22 F872046006 Washer Ø 12 6
23 F035000070 Connecting rod screw 6
26 F871115152 Screw M6 x 14 16
27 F040000070 Lower cover 1
28 F080600130 Lower cover gasket 1
29 F060100220 Crankcase 1
30 F034000010 Pin 301
31 F811110016 Bearing 1
32 F881080032 Oil seal Ø 70 x 90 x 10 1
33 F063400640 Bearing cover (direct drive version) 1
34 F881080031 Oil seal Ø 65 x 90 x 10 1
35 F080600110 Bearing cover gasket 2
36 F801057002 Magnetic plug G 1/2” 1
37 F872043002 Aluminum washer Ø 12 1
38 F063400540 Back cover 1
39 F871121152 Screw M8 x 20 6
40 F080600100 Back cover gasket 1
41 F001000010 Oil digstick 2
42 F872041501 Washer Ø 3/8” 2
43 F872026003 Eyebolt M16 2
44 F030000030 Eyebolt spacer 2-4
45 F801054027 Filling plug G 1” 1
46 F881010116 O-ring Ø 29.82 x 2.62 1
47 F801056002 Venting plug G 1/2” 1
48 F040000050 Upper cover 1
49 F080600120 Upper cover gasket 1
50 F872100005 Crankshaft key 1
51 F050000100 Crankshaft 1
52 F811111008 Bearing 1
53 F811920004 Bearing bushing 1
54 F872069012 Washer MB12 1
55 F872020012 Ring nut KM12 1
56 F063400580 Bearing cover 1
57 F821204051 Plug M10 x 1 3
58 F250000020 Connecting rod assembly 3
59 F250001100 Piston assembly 3
60 F872142015 Retainer pin Ø 5 x 36 3
61 F071000060 Wrist pin Ø 28 3
Item Part # Description QTY.
62 F881081000 Oil seal Ø 32 x 45 x 6.5 Spec. 3
63 F881010127 O-ring Ø 64.77 x 2.62 3
64 F063400560 Piston oil seal cover 3
65 F206000000 Wiper 3
66 F881012115 O-ring Ø 26.65 x 2.62 3
67 F031200470 Wiper spacer 3
68 F124200550 Plunger VS16 3
F124200560 Plunger VS18 3
F124200570 Plunger VS20 3
F124200580 Plunger VS22 3
F124200590 Plunger VS24 3
69 F035000200 Packing support screw 18
70 F872071530 Seeger Ø 52 inox 3
71 F031300240 Scraper ring VS16 3
F031300230 Scraper ring VS18 3
F031300170 Scraper ring VS20 3
F031300180 Scraper ring VS22 3
F031300220 Scraper ring VS24 3
72 F881030007 Seal ring VS16 3
F881030008 Seal ring VS18 3
F881030009 Seal ring VS20 3
F881030010 Seal ring VS22 3
F881030040 Seal ring VS24 3
73 F881010122 O-ring Ø 47.30 x 2.62 3
74 F022200140 Packing support VS16 3
F022200150 Packing support VS18 3
F022200160 Packing support VS20 3
F022200170 Packing support VS22 3
F022200180 Packing support VS24 3
75 F881018001 O-ring Ø 45.52 x 2.62 Spec. 3
76 F062200540 Cylinder 3
77 F881010142 O-ring Ø 75.87 x 2.62 3
78 F064400040 Collector 1
79 F881010109 O-ring Ø 5.32 x 2.62 9
80 F083500040 Cooling system tip 3
81 F205000130 Pressure packing kit VS16 3
F205000140 Pressure packing kit VS18 3
F205000150 Pressure packing kit VS20 3
F205000160 Pressure packing kit VS22 3
F205000170 Pressure packing kit VS24 3
82 F031500250 Pressure packing retaining bushing VS16 3
F031500260 Pressure packing retaining bushing VS18 3
F031500270 Pressure packing retaining bushing VS20 3
F031500280 Pressure packing retaining bushing VS22 3
F031500290 Pressure packing bushing VS24 3
83 F090200260 Suction valve spring 3
84 F082200230 Suction valve poppet 3
85 F080500170 Valve seat ring (suction side) 3
86 F081200570 Valve seat 3
87 F080500160 Valve seat ring (delivery side) 3
88 F082200220 Delivery valve poppet 3
89 F090200170 Delivery valve spring 3
90 F021300390 Delivery valve guide 3
91 F208007000 Valve assembly 3
92 F821203100 Plug G 1/8” 4
93 F872042000 Aluminum washer Ø 10 4
94 F801203030 Quick coupling G 3/8” 1
95 F871145973 Screw M18 x 300 Spec. 8
96 F063200190 Valve cover 3
97 F871135302 Screw M14 x 40 Spec. 12
98 F010500050 Anti-extrusion ring 3
99 F881010207 O-ring Ø 28.17 x 3.53 Spec. 3
100 F064200330 Manifold 1
101 680086 Conical seal G 1/2” 2
102 F052000290 Pinion 1800 RPM (Z24) 1
F052000320 Pinion 1500 RPM (Z27) 1
103 F811110014 Bearing 1
104 F063100210 Hydraulic motor flange 1
Ref 300509 Rev.C
03-12
