GENERAL PUMP

A member of the Interpump Group

LK55 SERIES

REPAIR KITS

Item Part #

Description

QTY.

50 F99369700

Bolt, M10x35

3

51

F74050043

Piston Guide

3

F74050343

Piston Guide

3

52 F99441000

Screw, M12x1.25x87

6

53 F78160020

Crankcase Cover

1

54 99305900

Screw, M8x20

23

55 F90417000

O-ring, Ø 355.19x3.53

1

56 F78010013

Crankcase

1

57 F98195500

Plug, Ø 9x10

1

58 F90069700

Ring, Snap

6

59 F97745000

Wrist Pin, Ø 35x64

3

60 F97597800

Oil Level Indicator, G1”

2

61 F78214200

Bearing Bushing

2

62 F78020035

Crankshaft Sleeve

1

63 F99426800

Screw, M12x25

8

64 F78213955

Bearing Bushibg Retainer Flange

2

65 F91886200

Roller Bearing

2

66 F78150220

Bearing Cover

2

67 F90392900

O-ring, Ø 152.07x2.62

2

68 F90394000

O-ring, Ø 183.62x2.62

2

69 99368600

Bolt, M10x30

12

70 F78150013

Bearing Cover

2

71

F90930000

Semi-circ. Connecting Rod, Inf.

3

F90930100

Semi-circ. Connecting Rod, +0.25, Inf.

3

F90930200

Semi-circ. Connecting Rod, +0.50, Inf.

3

72

F90931000

Semi-circ. Connecting Rod, Sup.

3

F90931100

Semi-circ. Connecting Rod, +0.25 Sup.

3

F90931200

Semi-circ. Connecting Rod, +0.50 Sup.

3

73 F78030101

Connecting Rod Assembly

3

74

F10072735

Bearing, External, Z59, R2,95

1

F70073135

Bearing, External, Z61, R3,389

1

F10072935

Bearing, External, Z60, R3,158

1

75

F10072835

Bearing, Internal, Z59, R2.95

1

F10073235

Bearing, Internal, Z61, R3,389

1

F10073035

Bearing, Internal, Z60, R3,158

1

76 F97618500

Pin, Locator, Ø 8x18

2

77 96751400

Gasket, Ø 21.5x27x1.5

2

78 F98218300

Plug, G1/2”x13

2

79 F98232800

Plug, Oil, G1”

1

80 F91501000

Key

1

81 F93105000

Lift Ring, M16

2

82 99183700

Screw, M6x14 Gr. 8.8

8

83 F98208700

Plug, 3/8”

1

84

F10073355

Pinion, Z20, R2,95

1

F10073555

Pinion, Z18, R3,389

1

F10073455

Pinion, Z19, R3,158

1

85 F78150120

Cover, Crankshaft End

1

86 F90172400

Ring, Rad., Ø 55x75x8

2

87 F78150320

Bearing Cover

1

88 90391800

O-ring, Ø 94.92x2.62

2

89 F91859700

Needle Bearing

4

90 F78214089

Spacer, External

2

91 F78214189

Spacer, Internal

2

92 F78214489

Lubricating Bushing

2

93 F78214389

Conical Lubrication Cover

2

94 90358100

O-ring, Ø 8.73x1.78

2

95 99308400

Screw, Hex, M8x30

8

96 F78150420

Bearing Cover

1

97 F90391350

O-ring, Ø 71.12x2.62 (LK50)

3

F90391450

O-ring, Ø 75.87x2.62(LK55, LK60)

3

98 F36208951

Internal Valve Guide

6

Item Part #

Description

QTY.

1

F120115

Manifold

1

2

F200030160

Suction Valve Device

3

3

F36206666

Seat, Valve, Inlet

3

4

F90527000

Anti-extrusion Ring, Ø 62.1x67x2

3

5

F90410500

O-ring, Ø 59.92x3.53

6

7

F36208701

Spherical Valve Assembly

6

8

F94769800

Spring, Ø 41.5x37.9

3

9

F36206051

Valve Cage

6

10 F36715001

Valve Assembly, Inlet

3

11 F74210551

Valve Part

3

12 90358400

O-ring, Ø 10.82x1.78

3

13 F98204600

Plug, G1/4”x13-INOX

3

14 F36206866

Seat, Valve, Outlet

3

15 F90527300

Anti-extrusion Ring, Ø 61.4x67.2x1.5

3

16 F90529000

Anti-extrusion Ring, Ø 77.2x83x1.5

3

17 F90413400

O-ring, Ø 75.8x3.53

6

18 F94770000

Spring, Ø 41.5x41.1

3

19 F36715201

Valve Assembly, Outlet

3

20 F74210970

Valve Plate

3

21 F90529300

Anti-extrusion Ring, Ø 77.4x83.2x1.5

3

22 F94800000

Spring, Ø 75x49.6

3

23 F74210766

Washer

3

24 F74210115

Valve Cover

1

25 F99521200

Screw, TCEI, M16x150

8

26 F99514700

Bolt, TCEI, M16x55

8

27 F71210456

Bolt, Plunger

3

28 F90367700

O-ring, Ø 14x2

3

29 F90418500

O-ring, Ø 72x4

3

30

F78214756

Plunger Guide, Ø 50 (LK50)

3

F78214856

Plunger Guide, Ø 55 (LK55)

3

F78214956

Plunger Guide, Ø 60 (LK60)

3

31

F74040209

Plunger, Ø 50x127 (LK50)

3

F74040309

Plunger, Ø 55x127 (LK55)

3

F74040409

Plunger, Ø 60x127 (LK60)

3

32 F90391450

O-ring, Ø 75.87x2.62

6

33

F74100292

Piston Ring, Ø 50 (LK50)

3

F74100392

Piston Ring, Ø 55 (LK55)

3

F74100492

Piston Ring, Ø 60 (LK60)

3

34

F90286300

Packing Retainer, Ø 50x65x7.5/4.5, H.P. (LK50)

3

F90287300

Packing Retainer, Ø 55x70x7.5,/4.5 H.P. (LK55)

3

F90288300

Packing Retainer, Ø 60x76x8/4.8, H.P. (LK60)

3

35

F90287500

Restop Ring, Ø 50x65x8/4.5 (LK50)

3

F90288500

Restop Ring, Ø 55x70x8/4.5 (LK55)

3

F90289500

Restop Ring, Ø 60x76x8/4.5 (LK60)

3

36

F90286000

Ring, Ø 50x58x5.5, L.P. (LK50)

3

F90287000

Ring, Ø 55x63x5.5, L.P. (LK55)

3

F90288000

Ring, Ø 60x68x5.5, L.P. (LK60)

3

37

F78215068

Packing Support Ø 50 (LK50)

3

F78215168

Packing Support Ø 55 (LK55)

3

F78215268

Packing Support Ø 60 (LK60)

3

38 F78214670

Wiper Ring

3

39 F78215302

Wiper

3

40 701111

O-ring, Ø 10.78x2.62

3

41 F74150222

Lower Cover

1

42 F90167900

Ring, Rad. 40x52x7

3

43 F78213771

Plunger Oil Seal Cover

3

44 F90391400

O-ring, Ø 72.69x2.62

3

45 F90450000

O-ring, Ø 266.06x5.34

2

46 F74150122

Upper Cover

1

47 F78050166

Plunger

3

48 F99191600

Screw, M6x30

3

49 F97674000

Spine, Ø 5x16

3

KIT

NUMBER

F2093 (LK50)

Plunger

Packing Kit

F2094 (LK55)

Plunger

Packing Kit

F2095 (LK60)

Plunger

Packing Kit

F2048

Valve Kit

F2097 (LK50)

Complete Seals Kit

F2098 (LK55)

Complete Seals Kit

F2099 (LK60)

Complete Seals Kit

F2076

Connecting

Rod Bushing Kit

F2077 +0.25

Connecting

Rod Bushing Kit

F2078 +0.50

Connecting

Rod Bushing Kit

Positions

Included

29, 32, 34,

35, 36, 97

29, 32, 34,

35, 36, 97

29, 32, 34,

35, 36, 97

10, 11,

17,

19, 21

4, 5, 12, 15, 16, 17, 21,

28, 29, 32, 34, 35, 36,

40, 42, 44, 45, 55, 67,

68, 86, 88, 94, 97

4, 5, 12, 15, 16, 17,

21, 28, 29, 32, 34, 35,

36, 40, 42, 44, 45, 55,

67, 68, 86, 88, 94, 97

4, 5, 12, 15, 16, 17, 21,

28, 29, 32, 34, 35, 36,

40, 42, 44, 45, 55, 67,

68, 86, 88, 94, 97

71, 72

71, 72

71, 72
