46
BE-15/15C PARTS LIST: UNITS A91 THRU E92
Part # Description Notes
M100860 Aspirator NO LONGER OFFERED
J101135 Barbed Hose Fitting For 1/2” hoses. 1/4” NPT threads.
J100634 Condenser Shell and tube heat exchanger.
J101108 Contactor NO LONGER OFFERED
A101104 Cooling Coil NO LONGER OFFERED
M100864 Cooling Coil Gasket NO LONGER OFFERED
J101114 Divert Solenoid Valve Divert Valve and 120-volt solenoid coil.
J101885 Divert Valve only NO LONGER OFFERED
A101179 Fan Blade assembly NO LONGER OFFERED
J101558 Fan Motor 1/8 hp, TEAO motor for fan.
J101300 Fill Funnel NO LONGER OFFERED
J101721 Fill or Drain Valve Ball valve in fill or drain piping.
J101104 Heater Band Exterior heater for Process Tank.
J101498 Heater Band Ceramic Terminal Caps NO LONGER OFFERED
J102319 Heater Band Strap, lower with loop Holds bottom of Heater Band, has loop.
J101499 Heater Band Strap, upper Holds top of Heater Band in place.
A101103 Hose Kit NO LONGER OFFERED
M100991 Insulation, bottom outside NO LONGER OFFERED
M100988 Insulation, Heater Band NO LONGER OFFERED
M100987 Insulation, Process Tank sides NO LONGER OFFERED
M100990 Insulation, Process Tank top NO LONGER OFFERED
J101130 Level Control Board NO LONGER OFFERED
J101129 Level Control Probe Senses liquid level in Process Tank.
J101105 On/off Switch 120-volt coil, circuit breaker type.
J101140 Petcock Drain Plug NO LONGER OFFERED
M100985 Plastic Skin, side NO LONGER OFFERED
M100986 Plastic Skin, top NO LONGER OFFERED
J101111 Pressure Relief Valve Protects Process Tank. Pops at 30 psi.
J101210 Radiator For Air-cooled units only.
J102467 Tape, 1/2” wide filament NO LONGER OFFERED
J101131 TAS1 NO LONGER OFFERED
J101621 TAS2 – N/C 385° F Process Tank overtemp switch.
J101119 TAS3 – N/O 280° F Divert control switch.
J102149 TAS4 – N/C 180° F Distillate Piping overtemp switch.
J101139 Terminal Strip block NO LONGER OFFERED
J100212 Vacuum Gage Measure vacuum from 0 to -28” Hg.
M100959 Vacuum/circulation Pump Elbow, Air-cooled Attaches to pump, hole for barb fitting.
J101514 Vacuum/circulation Pump Elbow, Water-cooled NO LONGER OFFERED
M101626 Vacuum/circulation Pump Housing Outside cover for pump.
M100862 Vacuum/circulation Pump Housing Cover Inside cover for housing and impeller.
J102774 Vacuum/circulation Pump Housing O-ring O-ring to seal housing to housing cover.
A101678 Vacuum/circulation Pump Impeller Plastic impeller for pump, less shaft.*
M100958 Vacuum/circulation Pump Impeller Shaft Stainless steel impeller shaft for pump.
J101444 Vacuum/circulation Pump Motor 1/2 hp, 3450 rpm, 230V, TEFC, C-face.
J101256 Vacuum/circulation Pump Seal Seal for pump.
A101193 Vacuum/circulation Pump, Air-cooled Whole pump assembly with motor.
A101109 Vacuum/circulation Pump, Water-cooled NO LONGER OFFERED
*Specify 3-1/2” diameter.
