2.3 Displayed Legends
(Center-of-Zero)
HILoAd
LoLoAd
LobAtt (Low Battery)
2.4 Blank Display
When the instrument is in the “OFF” condition, the liquid
crystal display is completely blank.
2.5 Low Battery Condition
If the instrument is operational (ON) and senses that the
input (battery pack) voltage is below the level which
guarantees correct weighing, it will turn OFF.
2.6 Low Battery Legend
When the instrument is first turned ON, the “LobAtt”
legend will appear briefly after warm-up and the instru-
ment will turn itself OFF if a low battery condition exists.
2.7 Back Panel Description
Battery
Bracket
Battery
Pack
3
1 2
2417a
FIGURE 2-2: BACK OF INSTRUMENT
1. Load cell, waterproof gland
2. Battery port with protective cap used when battery
cable is disconnected
3. Battery cable
6
