Section 1: General Information
11/08 8 51206 Rev. 1
1.1.1. Specifications, Continued
Feature Description
Scale Construction • Type A36 carbon steel
• Deck plate – ¼” to ½”
• Full I-beam support
• Diamond Tread
Junction Box
• Watertight Analog
• Stainless Steel
• NEMA 4X
Load Cells
• Four (4) Rocker Column Design
• IP69K “True” Hermetically Sealed
• 17-4 ph Stainless Steel
• 15,000 to 50,000 Capacity
• Combined Error -- +/< 0.02% of Rated Capacity
Interface Cable 31’ PVC Jacketed
Approvals • FM Approved
• NTEP Approval CC# 07-097 (for 6,000 divisions)
• Load Cell NTEP Approval CC# 07-037
Standard Platform dimensions: 4’ x 4’ thru 6’ x 8. Height: 8” or 9”.
Scale Capacities: 20K, 40K & 60K. Steel Deck: ¼” – ½”. J-Box: NEMA 4X.
